Murphy L129CK1 Lube Level Swichgage
The L129 Series Lube Level Swichgage instrument is a combination lube level indicating gage and adjustable low and high limit switches. It provides protection against low oil level or high level caused by overfill or fuel or water seepage into the crankcase.
Check lube level without shutting down
Use on engines, pumps and compressors
Combination indicating gage with low and high limit switch
Float operated
The model L129CK1 is designed for grounded, low voltage electrical systems. It features a one-wire-to-ground electrical circuit. The L129CK1 was designed for applications requiring a three-wire, above ground electrical circuit. It features ungrounded contacts and a conduit hub to protect electrical wiring. Options are available for both models.
Case: Die-cast aluminum
Lens: Tempered glass
Maximum Working Pressure: 10 psi (68.9 kPa)
Process Connection: 1/2 NPT
Float Material: Brass
Contact Rating: 2 A @ 30 VAC/DC, pilot duty
