SGM-S 70 G1/4-IG PNP
Part no.: 10.01.17.00203
Magnetic gripper for handling metal sheets with holes
The SGM-S 70 G1/4-IG PNP is a specialized magnetic gripper designed for handling ferromagnetic workpieces, such as perforated metal sheets and complex laser-cut parts.
Product Overview
Brand and Series: Schmalz, SGM-S Series
Model: SGM-S 70 G1/4-IG PNP
Design: Compact and lightweight, with an easy-to-replace friction ring that can absorb high lateral forces.
Material: Constructed using durable materials suitable for industrial applications.
Key Features
Magnetic Technology:
Utilizes permanent magnets, allowing for safe handling without the need for a voltage source.
Suitable for handling ferromagnetic materials, including perforated metal sheets and parts with holes.
PNP Switching Function:
Equipped with a PNP switching function sensor, which switches to a positive signal when activated.
This feature enables seamless integration with automated systems and control units.
Connections and Compatibility:
Features a G1/4-IG connection, which is compatible with a wide range of pneumatic and hydraulic systems.
Easily integrates into existing manufacturing processes and automation systems.
Performance Specifications:
Designed to handle workpieces within a certain weight and size range, ensuring reliable and consistent performance.
Specific performance metrics, such as holding force and maximum lateral force absorption, are tailored to meet the needs of various industrial applications.
Applications
The SGM-S 70 G1/4-IG PNP magnetic gripper is ideal for use in a variety of industrial applications, including:
Automated Assembly Lines: Facilitates the handling and assembly of ferromagnetic parts with high precision and efficiency.
Material Handling Systems: Enhances the automation of material handling processes, reducing manual intervention and improving productivity.
Robotic Workcells: Integrates seamlessly with robotic arms and other automation equipment, enabling the automation of complex handling tasks.
Benefits
Increased Efficiency: Automates the handling of ferromagnetic workpieces, reducing manual labor and increasing overall production efficiency.
Improved Safety: Utilizes permanent magnets for safe handling, minimizing the risk of accidents and injuries.
Versatility: Suitable for a wide range of industrial applications, making it a versatile addition to any manufacturing process.
