Compact yet powerful, ideal for versatile applications
Beyond rotary operations, SCHUNK manual lathe chucks are equally suited for stationary use. Whether it’s the ROTA-S plus 2.0 with a base plate and quick-change jaw system, the jaw cassette-equipped model, or the lightweight ROTA-S flex chuck, all maximize machine tool capabilities—making SCHUNK manual chucks the perfect choice when hydraulic systems are unavailable.
Key Features:
Ultra-compact design optimizes workspace utilization.
Quick-change jaw system enables rapid tooling adjustments.
Maximum repeatability in jaw replacement ensures precision.
Exceptionally lightweight lathe chuck (ROTA-S flex) reduces load on machine spindles.
Available with base plate or cylindrical recess mounting options for flexible integration.
Description ID Machine interface Serration Size
ROTA-M flex 2+2 260 Z220-SV90° 1389670 ISO 702-4 Nr. 8 (Z220) 1/16" x 90° 260
ROTA-M flex 2+2 315 Z220-SV90° 1400911 ISO 702-4 Nr. 8 (Z220) 1/16" x 90° 315
ROTA-M flex 2+2 400 Z380-SV90° 1407684 ISO 702-4 Nr. 15 (Z380) 1/16" x 90° 400
ROTA-M flex 2+2 500 Z380-SV90° 1573344 ISO 702-4 Nr. 15 (Z380) 3/32" x 90° 500
ROTA-ML flex 2+2 500 SV90° 1583348 - 3/32" x 90° 500
ROTA-ML flex 2+2 630 SV90° 1570299 - 3/32" x 90° 630
ROTA-ML flex 2+2 800 M2 1573345 - Modul 2 800
ROTA-ML flex 2+2 1000 M2 1573346 - Modul 2 1000
ROTA-ML flex 2+2 1200 M2 1573347 - Modul 2 1200
