GEMS PS61-10-4MGS-B-SP Pressure Switch
Product Description
Compact pressure switches designed for OEM applications.
Equipped with high test pressure capabilities for demanding hydraulic applications such as forklifts, scissor lifts and off-road equipment.
Varies from 15 to 3000 psi (1 to 207 bar) - please check specific pressure range for required model
Excellent size to pressure range ratio
Adjustable or factory set
Particularly suitable for demanding OHV applications
Approvals
CE (limits switch voltage to 42 V DC)
GEMS Pressure Switch PS61-10-4MGS-B-SP Product Specifications
Pressure Range 0.7 → 4.1 bar
Media Measurement Gas, Liquid
Output Type SPST - Normally Closed
Minimum Pressure Reading 0.7 bar
Process Connection BSP 1/4
Maximum Pressure Reading 4.1 bar
Electrical Connection 1/4 x 1/32 Spade Wire Terminal Block
Minimum Operating Temperature -40°C
Maximum Operating Temperature +121°C
Accuracy ±0.1 bar
Mounting Type Threaded Mount
Housing Material Galvanized Steel
