GEMS 2600BGA1019M3HA018 Pressure Sensor
Core features
High precision and stability: Adopting CVD (chemical vapor deposition) sensing technology, it has excellent long-term stability (annual drift ≤ 0.2% FS), suitable for long-term monitoring scenarios.
All-metal welded structure: All stainless steel wet parts and metal welded electrical backend, strong corrosion resistance, suitable for harsh industrial environments.
Immersed design: Optimized for submersible level measurement, supports atmospheric pressure water tank or open channel water level monitoring, head pressure is 100mbar/m.
Technical parameters
Range: 0-1 bar (other pressure ranges can be customized).
Output signal: 4-20mA current output, compatible with 24VDC power supply (7-35VDC wide voltage range).
Protection level: IP68, suitable for underwater or high humidity environments.
Temperature range:
Compensation temperature: -20℃ to 80℃;
Operating temperature: -40℃ to 125℃
Structure and interface
Dimensions: body diameter 27.3mm, length 100mm (including cable).
Electrical connection: connected by molded cable, supporting customized interface configuration.
Material: all stainless steel wet parts, strong corrosion resistance.
Application scenarios
Industrial measurement: tank level monitoring, water treatment system, medical equipment, engineering machinery, etc.
Environmental monitoring: open channel water level, river and lake water level monitoring.
Special fields: semiconductor equipment, power plants, HVAC systems and other high-precision pressure/liquid level demand scenarios.
