Sprecher+Schuh V7-WD4DF Terminal Block
1. Product Overview
Model: V7-WD4DF
Type: Industrial-grade terminal block (with fuse holder)
Brand: Sprecher+Schuh (German professional electrical connection technology brand)
Application: For safe connection and circuit protection of power distribution system
2. Core parameters
Item Specification
Rated current 32A
Rated voltage 800V AC/DC
Number of poles 4 poles (4P)
Fuse type 10×38mm gG/gL type (maximum 32A)
Wiring capacity 0.2-16mm² (flexible wire)/1.5-25mm² (rigid wire)
Protection level IP20 (after installation)
3. Product features
Built-in fuse holder (visible fuse indication window)
Touch-proof design (compliance with IEC 60529)
Fast fault isolation
Industrial-grade structure:
Tinned copper alloy conductor
Flame-retardant housing (UL94 V0)
Vibration resistance (10-150Hz/2g)
Installation advantages:
35mm DIN rail mounting
Extensible bridge system
Transparent dust cover (optional)
